im 3081 version DC motorZ4-100-440V-IC06-B5

Z4 Series DC Motors: Center Height 100~450mm - is a standard series of small DC motors specified by the People's Republic of China machinery industry standard JB/T6316-2006 "Specifications for Z4 Series DC Motors".

Z4 series DC motors (center height 100~450mm) can be widely used in rolling mills of iron and steel industry, metal cutting machines, paper making, dyeing and weaving, printing, cement industry, plastic extrusion machines and other industries, suitable for a wide range of speed regulation, the overload capacity is no more than 1.6 times the electrical resistance.Regulation range speed by means of a weak-magnetic constant power motor, the upward direction can be 1.0-3.0 times the rated speed for different specifications, and the constant torque reduces the armature voltage, and the downward speed adjustment can reach as little as 20 rpm. The engine is characterized by continuous operation and a constant flow rate. If the altitude above sea level does not exceed 1000 m and the ambient temperature does not exceed 40 degrees, the engine can be designed in accordance with the data given in the technical data sheet. Operation: Motors in this series have class F insulation.
